Length Overall 29.8 metres

Beam 11.0 metres

Draught (hull) 2.2-2.5 metres

Fuel 10 m³

Fresh Water 2 m³

Max Speed 40+ knots

Aluminium Hull & Superstructure

Engine Options

• 3 x MAN D2862 LE489 IMO Tier 3 Diesel Engines, 1066bkW @ 2100rpm

• 3 x MTU 16V 2000M72 IMO 3 Diesel Engines, 1440bkW @ 2250rpm

• Up to 4 x MAN D2862 LE489 IMO Tier 3 Diesel Engines, 1066bkW @ 2100rpm

Propulsion

• 3 x Hamilton HTx52 Waterjets

• 3 x Hamilton HTx65 Waterjets

• 2 x Servogear HD295PTI Hybrid Ready CPP

2 x CAT Marine Generator Set, 44 ekW (55kVA) 380/220V, 60HZ

Crew 4

Passengers 24

High Speed Craft Passenger Notation

Sleek hull design for class leading efficiency

Semi-SWATH (Small-Waterplane-Area)

Excellent soft motion during transfer

Active forward hydrofoil

150 m² of large foredeck area with capacity for 1 x 20ft container or 2 x 10 ft containers

Safe personal transfer up to 3m significant wave height

Transit operations can continue up to 4m significant wave height
