80 Passengers, 40 knots
-
Length Overall 34.0 metres
Beam 12.5 metres
Draught 2.5 metres
Fuel 30 m³
Fresh Water 10 m³
Max Speed 40+ knots
-
Aluminium Hull & Superstructure
-
Engine
3 x MTU 16V2000 M72, Marine Diesel Engines, 1440W
Propulsion
3 x Hamilton HTX65 Waterjet
-
2 x CAT Marine Generator Set, 44 ekW (55kVA) 380/220V, 60HZ
-
Crew
2 x Officer
4 x Double Crew
Passengers
80
-
Sleek new generation hull design
Three drivelines support refined manoeuvrability and component redundancy
Semi-SWATH (Small-Waterplane-Area)
Excellent soft motion during transfer
Forward hydrofoil
63 m² of large foredeck area with capacity for 1 x 20ft container or 2 x 10 ft containers
Safe personal transfer up to 3m significant wave height
Transit operations can continue up to 4m significant wave height
