80 Passengers, 40 knots

    • Length Overall 34.0 metres

    • Beam 12.5 metres

    • Draught 2.5 metres

    • Fuel 30 m³

    • Fresh Water 10 m³

    • Max Speed 40+ knots

    • Aluminium Hull & Superstructure

    • Engine

      3 x MTU 16V2000 M72, Marine Diesel Engines, 1440W

    • Propulsion

    3 x Hamilton HTX65 Waterjet

    • 2 x CAT Marine Generator Set, 44 ekW (55kVA) 380/220V, 60HZ

  • Crew

    • 2 x Officer

    • 4 x Double Crew

    Passengers

    • 80

    • Sleek new generation hull design

    • Three drivelines support refined manoeuvrability and component redundancy

    • Semi-SWATH (Small-Waterplane-Area)

    • Excellent soft motion during transfer

    • Forward hydrofoil

    • 63 m² of large foredeck area with capacity for 1 x 20ft container or 2 x 10 ft containers

    • Safe personal transfer up to 3m significant wave height

    • Transit operations can continue up to 4m significant wave height
